What is the problem with the angle iron punching machine cutting continuously?

What is the problem with the angle iron punching machine cutting continuously?

Below is an answer to the question of the continuous cutting of angle iron punching machine:

  1. Abnormal deep time system: causing inaccurate timing or unstable power supply to the solenoid valve; Need to replace the time-based relay.
  2. Abnormal travel switch: sometimes it works, sometimes it doesn't work; Need to replace the travel switch.
  3. Loose electrical components such as relays: causing poor contact and resulting in the directional valve not being in place; Need to tighten the connecting wire end.
  4. Oil pump wear: leading to insufficient oil supply; The oil pump needs to be replaced.
  5. Internal leakage of oil cylinder: causing pressure relief; The oil cylinder seal needs to be replaced.
  6. The hydraulic oil is too dirty and the oil inlet filter is blocked, resulting in insufficient oil supply; Need to clean or replace the filter element.
  7. Electromagnetic valve core jamming and blockage: causing insufficient supply to the oil cylinder; Need to clean the solenoid valve core
    The above is the answer to the question of what the angle iron punching machine is constantly cutting. I hope it is helpful.
