Here's how to install the threading machine teeth:
- Select the appropriate die set based on the diameter of the pipe. (There are two sets of numbers on each set of teeth, one set is the specification of the teeth, each one is the same, such as 3/4, and the other set is the installation sequence number, such as 1, 2, 3, 4)
- Remove (lift) the die head from the carriage, loosen the handle nut, and rotate the curve disc to the maximum position on the scale.
- Install the selected set of teeth into the tooth socket one by one according to the corresponding sequence number, and the locking gap will match the curve disc. Then turn the curve disc to align the scale indicator line on the curve disc with the scale of the required workpiece, tighten the handle nut, and the teeth will be correctly positioned. Lift up the teeth head for later use.
- Spiral the variable pitch to the desired specification position.
The above are the steps for installing the die, hoping to be helpful to everyone.
